A Study Battery System for Electric Vehicle Body Design through Structural Simulation

Jae-Woong Lee

doi:10.22680/kasa2026.18.1.134

All Issue

2026 Vol.18, Issue 1 Preview Page

A Study Battery System for Electric Vehicle Body Design through Structural Simulation 구조해석을 통한 전기자동차 차체 설계를 위한 배터리 시스템에 관한 연구

31 March 2026. pp. 134-140

PDF XML

Abstract

In the case of electric vehicles, the motor system can replace the combustion engine and provides an environmentally sustainable and very attractive power source. However, due to the low power performance of the motor and battery, the weight of the electric vehicle increases significantly to increase the efficiency. In this study, a stiffness analysis was performed to evaluate the safety due to the increased weight of the battery-mounted parts. For this purpose, a CAE (computer-aided engineering) simulation was performed on the entire vehicle (Metro by Geo Co. = base model) model. After the dynamic stiffness analysis, a stiffness enhancement design was proposed to evaluate whether the stiffness of the surrounding structure is safe when the battery is mounted, and a design change idea was proposed to improve the stiffness of the base model. Based on this, a new floor structure was proposed to mount the battery on the vehicle. The new concept model suggests a new design direction as an integrated BIW (body in white) that can easily replace a discharged battery with a newly charged battery, which can be helpful for the future design of advanced electric vehicles.

Keywords

Electric vehicle(전기자동차)

Motor(모터)

Battery(배터리)

Safety(안전성)

Light-weight design(경량설계)

References

G. Belingardi and A. Scattina, 2023, “Battery pack and underbody: integration in the structure design for battery electric vehicle- Challenges and solutions,” Vehicles, Vol. 5, No. 2, pp. 498~514.

10.3390/vehicles5020028

P. Huang, F. Lan, and J. Chen, 2017, “The structural response analysis of EV battery packk under random vibration and impact conditions”, Automotive Engineering, Vol. 39, No. 9, pp. 1087~1093.

F. Dohmann and Ch. Hartl, 1997, “Tube hydroforming-research and practical application,” J. Mater. Process. Tech., Vol. 71, pp. 174~186.

10.1016/S0924-0136(97)00166-0

K. J. Kim, B.-I. Choi, and C. W. Sung, 2008, “Hydro-forming Process of Automotive Engine Cradle by Computer Aided Engineering (CAE),” KSAE, Vol. 16, No. 1, pp. 86~92.

K. J. Kim, J. h. Kim, and B.-I. Choi, 2010, “Hydro-forming Process Development of Automotive AA6061 Rear Sub-frame Side Member by Computer Aided Engineering (CAE),” KSAE, Vol. 18, No. 5, pp. 45~49.

C. W. Sung and Y. N. Paik, 2008, “Hydro-Forming Simulation of Automotive Rear Sub-frame Cross Members,” KSMT, Vol. 10, No. 2, pp. 9~14.

10.17958/ksmt.10.2.200806.9

M. Cerit and M. Coban, 2014, “Temperature and thermal stress analyses of a ceramic-coated aluminum alloy piston used in a diesel engine,” International Journal of Thermal Sciences, Vol. 77, pp. 11~18.

10.1016/j.ijthermalsci.2013.10.009

B. Zhao, 2012, “Thermal Stress Analysis of Ceramic-Coated Diesel Engine Pistons on the Wavelet Finite-Element Method,” Journal of Engineering Mechanics, Vol. 138, No. 1, pp. 143~149.

10.1061/(ASCE)EM.1943-7889.0000302

Information

Publisher :Korean Auto-vehicle Safety Association
Publisher(Ko) :한국자동차모빌리티안전학회
Journal Title :Journal of Auto-vehicle Safety Association
Journal Title(Ko) :자동차안전학회지
Volume : 18
No :1
Pages :134-140
Received Date : 2026-01-28
Revised Date : 2026-02-18
Accepted Date : 2026-02-23
DOI :https://doi.org/10.22680/kasa2026.18.1.134
